2RV/2RW/2RX/2RY/3RA-3

7-113

(8) Abnormal sound from the lower side than the fuser exit section

Friction sound between the lower exit roller bushing and stop ring due to adhesion of dirt and foreign objects

(9) Abnormal sound from the upper side of the fuser exit section

Friction sound between the lower exit pulley and shaft due to adhesion of dirt and foreign objects

(10)Abnormal sound from the fuser section

Dirt at the fuser section, foreign object adhesion, contact of parts

(11)Abnormal sound from inside the machine

Toner shutter open/close failure of the toner container, toner quantity lack, or toner aggregation

Step Check description Assumed cause Measures Reference

1 Cleaning and applying the

grease

The lower exit roller, bush-

ing, stop ring, etc. are dirty

or foreign objects adhere

to them.

Clean the lower exit roller,

bushing, stop ring, etc. and

apply heat-resistant grease.

2 Replacing the fuser unit The fuser unit is faulty. Replace the fuser unit.

Step Check description Assumed cause Measures Reference

1 Cleaning and applying the

grease

The pulley or the shaft is

dirty, or foreign objects

adhere on them.

Clean the lower exit roller and

shaft, and apply heat-resis-

tant grease.

2 Replacing the fuser unit The fuser unit is faulty. Replace the fuser unit.

Step Check description Assumed cause Measures Reference

1 Cleaning and applying the

grease

The bushing or the gear is

dirty or foreign objects are

on them.

Clean the fuser belt, fuser

press roller bushing and gear

and apply grease.

2 Cleaning and applying the

grease

The shaft is dirty or foreign

objects adhere to it.

Clean the lower exit roller and

shaft,etc., and apply heat-

resistant grease.

3 Cleaning and applying the

grease

The gear is dirty or foreign

objects adhere to it.

Clean the fuser drive gear

and apply the grease to it.

4 Applying the grease The grease is not enough. Apply the grease to the pres-

sure release cam and the

frame.

5 Replacing the fuser unit The fuser front guide is

warped and contacts the

fuser press roller.

Replace the fuser unit.

Step Check description Assumed cause Measures Reference

1 Checking the toner supply

opening

The spring to open/close

the toner shutter is caught

up or deformed.

Open and close the toner

supply opening manually to

fix the operation.
