Kyocera FS-1060DN User Manual

2M2/2M3
2-4-18
(2) Wiring diagram
No.1
DDR1 MEMORY
LAN
USB
DEBUGGER
SERIAL I/F
CEBU ASIC
ENGINE
CPU
AC IN
+3.3V3 LONBN LDCONT PDN GND LDENBN VIDEO VIDEON
+24V3 GND POLONN POLORDYN POLCLK
PM
OUTA OUTB
+24V3 FANDRN
FM
GND TONER SENSOR +24V3
TS
+24V3 FFEDSOLDRN +24V3 DUSOLDRN
RS
+24V3 +24V3 DUSOLDRN FEEDSOLDRN FANDRN MOTCLK GND PULSE REGIST TONERSENS +3.3V3 SECCLK SECDATA GND THERM
+3.3V3 FTHERM
KEY1 KEY2 KEY3 LED1 LED2 LED3 GND
DUS
BK
WE
RD
+24V2 +24V2 ZCROSS RELAY HEATREM PUSHSW +24V1 GND GND
+24V2 +24V3
1
4
LIVE
NEUTRAL
1
4
3
1
FH
3
2
1
FUSER UNIT
RELAY
CSW
APC PWB
1 2 3 4 5
YC17
5 4 3 2 1
5 4 3 2 1
1 2 3 4 5
LSU UNIT
HVPWB
YC13
+24V3 HVCLK RTHVDR MCNT TCNT MISENS GND
1 2 3 4 5 6 7 1 2 3 4 5 6 7
7 6 5 4 3 2 1
I
2
C Bus I/F
FRAM
1 2
1 2
1 2
1 2 3
1 2 3
1 2 3 4
+3.3V3 SECCLK SECDATA GND
1 2
PFSOL DUSOL
1 2
1 2
1 2
1 2
3 2 1
1 2 3
1 2 3
15 14 13 12 11 10
9 8 7 6 5 4 3 2
1
1 2
1 2
1 2 3 4 5 6 7 8 9
10
1 2 3 4 5 6 7 8 9
10
10
9 8 7 6 5 4 3 2 1
10
9 8 7 6 5 4 3 2 1
1 2 3 4
+3.3V3REG GND REGIST
OPWB
YC1
1 2 3 4 5 6 7
3 2 1
1 2 3
1 2 3
+3.3VEXIT GND EXIT
3 2 1
3 2 1
2
1
2
1
1 2
1 2
1 2
1 2
2 1
2 1
+3.3V3 THERM
OTEMS
RPWB
WE
GY
BE
YW
2 1
1 2
2 1
1 2
2 1
1 2
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
+24VERASER ERASER
PSSLEEPN
YC12
YC20
YC6
YC16
25ppm model only
YC15
YC5
YC1
YC14
YC2 YC3 YC4 YC6 YC5 YC7 YC8 YC9
25ppm model only
YC102
YC101
MPWB
PSW
Charger roller
Transfer roller
Developer
ELPWB
MM
FTS
PSPWB
FTH
CPWB
MCS
LIVE
NEUTRAL
YC103
YC1
YC101
M
B
T

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
