Kyocera FS-1060DN User Manual

2M2/2M3
1-4-13
(11) Offset occurs.
(12) Fusing is loose.
(13) Faint or blurred printing
Print example Causes Check procedures/corrective measures
Deformed or worn cleaning
blade in the drum unit.
Replace the drum unit (see page 2-4-11).
Main charge voltage setting. The main charge voltage may be set too high. Try adjust-
ing the main charge voltage (see page 1-3-11).
Defective fuser unit. Replace the fuser unit (see page 1-5-6).
Wrong types of paper. Check if the paper meets specifications. Replace paper.
Print example Causes Check procedures/corrective measures
Wrong types of paper. Check if the paper meets specifications, replace paper.
Flawed heat roller or press
roller.
Replace the fuser unit (see page 1-5-6).
Defective pressure springs.
Print example Causes Check procedures/corrective measures
Wrong types of paper. Check if the paper meets specifications,
replace paper.
Drum condensation.
Perform the drum refresh (see page 1-3-11).
Defective transfer roller installation. The transfer roller must be supported by the
bushes at the both ends. Replace the transfer
roller if it is extremely dirty (see page 2-4-12).
Defective
transfer
bias output.
Defective high voltage PWB Replace the high voltage PWB
(see page 1-5-7).
Defective main PWB. Replace the main PWB (see page 1-5-7).

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
