Kyocera FS-1350DN User Guide

Imaging
This setting creates a PostScript file in ASCII text encoding. Unlike the binary
format created in Fast printing, the ASCII text created with this selection
can be edited.
CIE Optimization
CIE optimization bypasses the normal procedure of processing every aspect of
the CIE color space used in applications such as Adobe Acrobat and
Photoshop. This feature increases print speed for documents printed from these
applications by optimizing CIE data. It has no effect on print jobs that do not use
CIE data. CIE optimization should be selected for speed not accuracy, so
printed output may be different from appearance on the screen.
In the Imaging tab, click Graphics to open the Graphics settings dialog box
and access the CIE optimization check box. CIE optimization is available
when KPDL is selected in Device Settings > PDL > Select PDL.
Note: If you are using the XPS driver on the Windows Vista operating system,
CIE optimization is unavailable.
Halftone Screen
Halftone Screen lets an experienced user print different shades of gray as are
found in photographs. Shades are produced by printing dots of various sizes
and shapes, and by spacing them closer or farther apart. Shading can also be
adjusted by the number of rows of data, the angle of the rows, and the shape of
the data.
Halftone Screen is available when KPDL or XPS is selected as the PDL. It is
unavailable if GDI compatible mode is selected in the PDL Settings dialog
box.
Setting the Halftone Screen
Halftone Screen provides a means to apply shades of gray to black and white
printed output.
1
In the Imaging tab, click Graphics > Halftone Screen.
2
Clear the Use printer's default screens check box.
3
Set the available options to the desired values:
Ink
Lists the halftone screens available. For black and white printers, this option
appears unavailable and is permanently set to Black.
Frequency
Displays the number of rows of dots per inch or centimeter. Set the range
from 2.0 to 999.9, and select lines/inch or lines/cm.
Angle
Sets the angle at which rows are aligned. Set the range from -180 to 180
degrees.
Shape
Select the shape of the halftone dot:
Ellipse
User Guide
6-5

Kyocera FS-1350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Processor model	PowerPC–440F5
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Power supply type	AC 220 - 240 V, 50/60 Hz
Capacity cartridge	7200 sheets
Standard media sizes	(105 x 148 - 216 x 297 mm)
Power consumption (active)	484 W
Compliance industry standards	TUV/GS, CE
Number of print cartridges	1
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum print size	216 x 356 mm
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power consumption (standby)	12 W
Power consumption (PowerSave)	7.1 W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 267 mm
