Computer Interface
4-5
USB Interface
This printer supports the Hi-Speed USB. USB (Universal Serial Bus) interface specifications and
interface signals are as follows.
Specifications
Basic specification
Complies with the Hi-Speed USB.
Connectors
Printer: B-type receptacle (female) with upstream port
Cable: B-type plug (male)
Cable
Use a shielded cable that complies with USB 2.0 (Hi-Speed USB) and not longer than 5 meters (16
feet).
Transfer Mode
High speed (480 Mbps maximum)
Power Control
Self-power device
Interface Signals
USB Connector Pin Assignment
Pin Signal Description
1 Vbus Power supply (+5 V)
2 D- Data transmission
3 D+ Data transmission
4 GND Signal ground
Shell — Shield
