Kyocera KM-1620 User Manual

Section 8 TROUBLESHOOTING
8-2
“E91” appears on the copy quantity display. Copies cannot be produced because memory is full during the interrupt
copy operation. Interrupt Copying cannot be carried out so press the
[Stop/Clear] key and then press the [Interrupt] key again after the data
read in has been deleted to exit the Interrupt Copying.
After the copying operation for the interrupted copy has been completed,
repeat the procedure again.
“OP” appears on the copy quantity display. The front cover of the copier is open. Close the front cover. –
“OP1” appears on the copy quantity display. The left cover of the Document Processor is open. Close the left cover. Close
the front cover.
–
“OP2” appears on the copy quantity display. The left cover of the copier is open. Close the left cover.
“OP3” – “OP5” appears on the copy quantity
display.
The left cover of the optional drawer is open. Close each of the left covers. –
“C” and a number are alternately displayed on
the copy quantity display.
Make a note of the C and the number. Turn the power switch OFF, unplug
the power cord and contact your service representative.
–
“A” and a number are alternately displayed in
the copy quantity display. (except A-3200)
Turn the power switch OFF/ON. Usage will be possible again once the
regular display returns. When A and the number are again displayed on
the copy quantity display, make a note of the A and the number. Turn the
power switch OFF, unplug the power cord and contact your service
representative.
–
“A3” and “200” are displayed alternately in the
copy quantity display.
Condensation is occurring within the copier. Turn the Power Switch OFF
and then turn it ON again after 10 to 20 minutes have elapsed.
–
The Paper Misfeed display blinks on and off and
“JXX” appears on the copy quantity display.
XX indicates the paper misfeed location
numerically.
A paper misfeed has occurred. Remove the jammed paper. 8-3
“OF” appears on the copy quantity display. 250 copies have been stored in the storage section. Remove the paper, press
the [Start] key and resume copying.
–
The Periodic Maintenance indicator blinks on
and off.
This is a notification that the time for periodic maintenance is approaching. –
The Periodic Maintenance indicator lights up. It is time for Periodic Maintenance. Contact your service representative. –
The Paper Supply indicator lights up and “PE”
appears on the copy quantity display.
There is no paper in the drawer level that corresponds to the lighting
indicator. Replenish the paper and set the drawer.
3-1
“PF” appears on the copy quantity display. Check the Multi-bypass Tray paper. Set paper in the Multi-bypass Tray in
the event there is no paper present there. When the Multi-bypass Tray
paper fails to be fed, reset the paper.
3-4
“U1 appears on the copy quantity display. Check the key counter or key card and make sure it is set properly. 7-4
“= = =” appears on the copy quantity display. Department Management being set. Use the Keypad to enter the assigned
Section Code to perform copying operations. Press the [Management] key
after copying is finished to display “= = =” again.
6-6
“-” appears on the copy quantity display. The copier is in the Off mode setting. Press the [Energy Saver] key to exit
the mode.
4-8
“---” appears on the copy quantity display. The copier is in the Low Power mode setting. Press any key to exit the
mode or in the case where the optional Document Processor is installed, set
an original in the Document Processor.
4-7
Display Corrective Procedure
Reference
Page

Kyocera KM-1620 Specifications

General

Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Custom media sizes	98x147 - 297x432 (mm)
Maximum print size	A3 (297 x 420 mm)
Standard media sizes	A3, A4, A5, Ledger, Letter, Legal, Folio
Zoom capability	50 - 200%
Maximum number of copies	250 copies
Copy speed (black, normal quality, A4)	16 cpm
Standard input capacity	300 sheets
Grayscale levels	256
Type	Digital copier
Dimensions (WxDxH)	574 x 552 x 502 mm
Number of print cartridges	1
Recommended media weight	45 - 160 g/m²
Compatible ink types, supplies	TK-410
Maximum duty cycle	20000 pages per month
Power requirements	220-240V, 50/60 Hz
Power consumption (standby)	88 W
Power consumption (typical)	356 W
Certification	GS TUV CE ISO 9001 ISO 14001

Weight and Dimensions

Weight	39000 g

Summary

Important Safety and Precautions

Caution Labels

Identifies safety labels attached to the product for hazard prevention.

Installation Precautions

Guidelines for safe and proper placement and environmental conditions for the copier.

Precautions for Use

Critical safety instructions for operating the copier to prevent damage or injury.

Handling Consumables Safely

Safety advice for handling toner containers and waste toner boxes.

Laser Safety Information

Information regarding the copier's Class 1 laser product classification and safety.

Names of Parts

Main Body Components

Operation Panel Controls

Preparations for Operation

Loading Paper into Drawers

Instructions on how to load paper into the copier's drawers.

Setting Paper on Multi-bypass Tray

Basic Operation Procedures

Enlargement and Reduction Modes

Copy Functions

Making 2-Sided Copies

Procedures for copying on both sides of the paper from various original types.

Page Separation/Split Copy Modes

Fitting Multiple Originals (2-in-1/4-in-1)

Program Function for Stored Settings

Copier Management

Copy Management Mode Overview

Overview of features for managing copy usage by department or section.

Department Code Operations Procedures

Default Setting Mode Overview

Changing Default Settings Procedures

Optional Equipment

Document Processor

Details on the automatic document feeder for scanning originals.

Troubleshooting

Error Message Displays

Lists common error codes and their corresponding corrective actions.

Paper Jam Removal Procedures

Step-by-step guide on how to clear paper jams from various locations.

Other Troubleshooting Issues

Addresses common copy quality problems and their solutions.
