Kyocera TASKalfa 2552ci - Loading in Cassette 2

To Next Page

To Previous Page

3-7

Preparation before Use > Loading Paper

Loading in Cassette 2

Pull the cassette completely out of the machine.

Adjust the paper length guide to the paper size required.

NOTE

Do not pull out more than one cassette at a time.

NOTE

When using 12×18" size paper, move the paper length guide to the extreme left and lay it

down.
