9-26
User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration
Obtain NW User Property
Set the required information to obtain the network user property from the LDAP server. The user name and E-mail
address obtained with this setting is shown in the user information, the status confirmation screen, and the header of
E-mail.
1
Display the screen.
1 [System Menu/Counter] key > [User Login/Job Accounting]
2 [User Login Setting] > [Obtain NW User Property] > [On]
2
Configure the settings.
[On] > Add information on each item > [OK]
To obtain the network user property from the LDAP server, [Network Authentication] must be selected for the
authentication method in "Enabling User Login Administration". Select "On" for "LDAP" in "Protocol Detail".
Enabling User Login Administration (page 9-3)
Protocol Settings (page 8-55)
If the login user name entry screen appears during operations, enter a login user name
and password, and select [Login]. For this, you need to login with administrator
privileges.
The factory default login user name and login password are set as shown below.
Item Descriptions
Server Name
*1
Enter the LDAP server name or the IP address (up to 64
characters). If a server name is not entered, user information will
be acquired from the server set for Network Authentication.
Port Port number for LDAP server. The default port number is 389.
Name 1
*2
Enter the LDAP Attribute to obtain the user name to be displayed
from the LDAP server (up to 32 characters).
Name 2
*3
Enter the LDAP Attribute to obtain the user name to be displayed
from the LDAP server (up to 32 characters).
E-mail Address
*4
Enter the LDAP Attribute to obtain the E-mail address from the
LDAP server (up to 32 characters).
Model Name Login User Name Login Password
2552ci 2500 2500
3252ci 3200 3200
4052ci 4000 4000
5052ci 5000 5000
6052ci 6000 6000
To Next Page
