4: Configuration Using Web-Manager
Figure 4-5. Hostlist Settings
2. Enter or modify the following fields:
Retry Settings
Retry Counter Enter the value for the number of times the UDS1100 should
attempt to retry connecting to the host list. The default setting
is 3.
Retry Timeout Enter the duration (in seconds) the UDS1100 should abandon
attempting a connection to the host list. The default setting is
250.
Host Information
Host Address Enter or modify the host’s IP address.
Port Enter the target port number.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Channel 1 Configuration
The Channel 1 configuration defines how the serial port responds to network and
serial communication.
Serial Settings
To configure the channel’s serial settings:
1. On the main menu, click Serial Settings (under Channel 1) to display the Serial
Settings window.
UDS1100 User Guide 29
