Lantronix UDS1100 User Manual

1
1
3
3
:
:
T
T
e
e
c
c
h
h
n
n
i
i
c
c
a
a
l
l
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Table 13-1. UDS1100 Technical Specifications
Category Description
CPU Lantronix DSTNI-EX 48 MHz clock
Internal CPU Memory 256 KB zero wait state SRAM
Flash 2 MB Flash
EEPROM 2 KB EEPROM
Serial Interface 1 DB25F DCE serial port
Software-selectable baud rate from 300 to 230 Kbaud
Software-selectable RS232, RS422 or RS485 (2 and 4 wire support)
Serial Line Formats Characters: 7 or 8 data bits
Stop bits: 1 or 2
Parity: odd, even, none
Modem Control DTR, DSR, DCD
Flow Control Hardware: CTS/RTS
Software: XON/XOFF
Power Input Standard UDS1100 (non-POE unit)
9-30 VDC or 9-24 VAC on barrel connector (1.5 Watts maximum consumption)
9-30 VDC on DB25F serial interface
UDS1100-POE only
802.3af Power over Ethernet (UDS1100-POE only)
Network Interface 1 RJ45 10Base-T/100Base-TX Ethernet port
Software selectable Ethernet speed 10/100/Auto
Software selectable Half/Full/Auto duplex
Dimensions Height: 2.3 cm (0.9 in)
Width: 6.4 cm (2.5 in)
Depth: 9.0 cm (3.5 in)
Weight 0.20 kg (0.45 lb)
Temperature Operating range: 0° to 60° C (32° to 140° F)
Note: Operating range for UDS1100-IAP only: -40° to 70° C (-40° to 158° F)
Storage -40° to 85° C (-40 to 185° F)
Relative Humidity Operating 10% to 90% non-condensing, 40% to 60% recommended
Storage 10% to 90% non-condensing
Case Metal enclosure with integrated wall mounts
Optional 35 mm Din Rail mount available
Protocols Supported ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, and HTTP
UDS1100 User Guide 75

Lantronix UDS1100 Specifications

General

Isolation	1.5 kV
Certification	UL, CSA, FCC, CE, TUV, CTick, VCC, UL 864 RoHS
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	100 - 240 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
