7: Setup Mode: Channel Configuration
Remote Port
You must set the remote TCP port number for the unit to make outgoing connections.
This parameter defines the port number on the target host to which a connection is
attempted.
Remote Port (0) ? _
To connect an ASCII terminal to a host using the unit for login purposes, use the
remote port number 23 (Internet standard port number for Telnet services).
Note: This option does not display when Hostlist is enabled from the
ConnectMode prompt (see Connect Mode on page 44 for more information).
DisConnMode
This setting determines the conditions under which the unit will cause a network
connection to terminate. The default setting is 00.
DisConnMode (00) ? _
Notes:
In DisConnMode (Disconnect Mode), when Modem Control In is not
asserted, this condition either drops the connection or is ignored.
All bit positions in the table that are blank represent “don’t care” bits for that
particular option, which can be set to either a 0 or 1 value.
Table 7-7. Disconnect Mode Options
Disconnect Mode Option 7 6 5 4 3 2 1 0
Disconnect when Modem Control In is not asserted
(6)
1
Ignore Modem Control In 0
Telnet Com Port Cntrl and terminal type setup
(1)
1
Channel (port) password
(2)
1
Hard disconnect
(3)
0
Disable hard disconnect 1
State LED off with connection
(4)
1
Disconnect with EOT (^D)
(5)
1
(1) The Telnet Com Port Control feature is used in conjunction with Com Port Redirector.
The UDS1100 sends the Terminal Type upon an outgoing connection.
(2) A password is required for a connection to the serial port from the network.
(3) The TCP connection closes even if the remote site does not acknowledge the
disconnection.
(4) When there is a network connection to or from the serial port, the state LED turns off
instead of blinking.
(5) When Ctrl+D or Hex 04 is detected, the connection is dropped. Both Telnet Com
Port Cntrl and Disconnect with EOT must be enabled for Disconnect with EOT to
function properly. Ctrl+D is only detected going from the serial port to the network.
(6) When Modem Control In transitions from a high state to a low state, the network
connection to or from the serial port drops.
UDS1100 User Guide 52
