Lantronix UDS1100 User Manual

Contents
Ethernet connection type _________________________________________ 57
Security Settings (Option 6)___________________________________________ 57
Disable SNMP__________________________________________________ 58
SNMP Community Name _________________________________________ 58
Disable Telnet Setup_____________________________________________ 58
Disable TFTP Firmware Update ____________________________________ 58
Disable Port 77FE (Hex) __________________________________________ 59
Disable Web Server _____________________________________________ 59
Disable Web Setup ______________________________________________ 59
Disable ECHO Ports _____________________________________________ 59
Enable Enhanced Password_______________________________________ 59
Default Settings (Option 7) ___________________________________________ 59
Channel 1 Configuration Defaults ___________________________________ 60
Expert Settings Defaults __________________________________________ 60
Security Settings Defaults_________________________________________ 60
9: Firmware Upgrades 61
Obtaining Firmware _________________________________________________ 61
Reloading Firmware ________________________________________________ 61
Using TFTP: Graphical User Interface _______________________________ 61
Using TFTP: Command Line Interface _______________________________ 62
Recovering the Firmware Using the Serial Port and DeviceInstaller_________ 62
10: Monitor Mode 64
Entering Monitor Mode Using the Serial Port __________________________ 64
Entering Monitor Mode Using the Network Port ________________________ 64
Monitor Mode Commands_________________________________________ 64
11: Troubleshooting and Contact Information 67
LEDs ____________________________________________________________ 67
Problems and Error Messages ________________________________________ 68
Technical Support __________________________________________________ 70
12: Connections and Pinouts 71
Serial Port _____________________________________________________ 71
Serial Connector Pinouts _________________________________________ 71
Modem Cable __________________________________________________ 72
Network Port ___________________________________________________ 73
Ethernet Connector Pinouts _______________________________________ 74
Power Plug ____________________________________________________ 74
13: Technical Specifications 75
A: Mounting Brackets 77
B: Alternative Ways to Assign an IP Address 78
DHCP ________________________________________________________ 78
AutoIP ________________________________________________________ 78
BOOTP _______________________________________________________ 79
UDS1100 User Guide 5

Lantronix UDS1100 Specifications

General

Isolation	1.5 kV
Certification	UL, CSA, FCC, CE, TUV, CTick, VCC, UL 864 RoHS
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	100 - 240 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
