Armed - The oscilloscope is acquiring pre-trigger data. All
triggers are ignored in this state.
Ready - The oscilloscope is ready to trigger.
Trig'd - The oscilloscope has found a trigger and is acquiring
the post-trigger data.
Stop - The oscilloscope has stopped acquiring waveform data.
Shown in red highlight.
Acq. Complete - The oscilloscope has completed a Single
Sequence acquisition.
Auto - The oscilloscope is in Auto Mode and is acquiring
waveforms in the absence of triggers.
Scan - The oscilloscope is acquiring and displaying waveform
data continuously in Scan Mode.
2. USB Memory Device - Indicates whether the USB Memory Device is
inserted in the USB Port.
When a USB Memory Device is not inserted in the USB Port
the area is blank.
USB Memory Device is inserted in the USB Port (as shown
previous).
When plugging in or removing a USB Memory Device, a
message is briefly shown on the grid display as USB Flash
Drive Plug In! and USB Flash Drive Pull Out!, respectively.
3. Waveform Preview Display - This small portion at the top of the
screen shows how much of the captured waveform is currently
appearing on the display.
Note: Show the full waveform by stopping the trigger and turning
the Time/Div button to the left (increasing the amount of time
shown on the display).
4. Print Key - Indicates whether the Print Key option is set to Print
Picture or Save Picture.
Print Key option set to Save Picture (as shown previous).
Print Key option set to Print Picture
