LeCroy WaveAce series User Manual

Getting Started Manual
WA-GSM-E RevB
66
Saving Waveforms to a USB Memory Device
 Insert the USB memory device, press the Save To option
button, and select File.
 Press the Save option button to save the waveform.
 The SAVE ALL screen is shown. See Using the SAVE ALL
Screen (on page 75) to continue saving onto your USB
memory device.
Recalling Waveforms
1. Press the Save/Recall front panel button. The SAVE/REC flyout
menu opens.
2. Press the Type option button and select Waveforms.
3. Recall the waveform either from internal memory or a USB
memory device using the following methods.
Recalling Waveforms from Internal Memory
 Press the Save To option button to select Device.
 Press the Waveform option button or turn the Universal
front panel knob to select the number assigned to the
waveform you want to recall.
 Press the Recall option button.
 The selected Waveform is recalled from memory and the
oscilloscope briefly shows a Read Data Success! message on
the lower part of the grid display area.
Recalling Waveforms from a USB Memory Device
 Insert the USB memory device and press the Save To option
button to select File.
 Press the Recall option button.
 The SAVE ALL screen is shown. See Using the SAVE ALL
Screen (on page 76) to continue recalling from your USB
memory device.
