The Record Menu (with Mode Set to Record)
Press the Mode option button and select Record. The Record menu (with
Mode set to Record) is shown and contains the following option button
functions (in addition to Mode).
1. Press the Source option button to choose from CH1 and CH2 (also,
CH3 and CH4 on four channel versions) as the recorded signal input.
2. Press the Interval option button and use the Adjust front panel
knob to dial in the desired interval between record frames.
3. Press the End Frame option button and use the Adjust front panel
knob to dial in the desired number of record frames.
4. Press the Operate option button to Start/Stop recording.
Note: A record: 1 counter is shown on the upper-left part of the
grid display area which counts the number of record frames to
your set End Frame amount.
The Record Menu (with Mode Set to Play Back) - Page 1/2
Press the Mode option button and select Play Back.
To Next Page
