92
1. Press the Enable Test option button to turn the function On or Off.
Note: Turning Enable Test On/Off allows you to control whether
or not the mask is shown on the display grid area while making
your settings. The Operate button runs the test and allows you to
see the results update in real time.
2. Press the Source option button and select a source (CHS 1 - 2; or
CHS 1 - 4 on 4 channel models).
3. Use the Operate option button to run and stop the Pass/Fail test.
4. Press the Msg Display option button to turn message display
On/Off during the Pass/Fail test.
