1.Installthesolid-statedriveintotheadapter.Then,installthefourscrewstosecurethesolid-state
drivetotheadapter.
Figure85.Installingthesolid-statedriveintotheadapter
2.Toinstalltheadapterwithasolid-statedriveintothebluebracket,flexthebracketandalignpin1,pin
2,pin3,andpin4onthebracketwiththecorrespondingholesintheadapter.Donottouchthecircuit
board5onthebottomofthesolid-statedrive.
Figure86.Installingtheadapterwithasolid-statedriveintothebracket
3.Installthesolid-statedriveassemblyintotheharddiskdrivebay.See“Replacingtheprimaryhard
diskdrive”onpage78
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage109.
88ThinkCentreM83,M93/pUserGuide
