Appendix A. Label locations
Figure 44. Label layout on the back side of the base cover
Labels attached to the base cover are country/region specific. Make sure to apply the appropriate labels to
the replacement base cover.
Table 5. All base cover labels
Label Label name
Applied country/region
Label dimensions
a
OS label
All 16 mm x 22.5 mm
b
Adapter Label Argentina
c
Country label
KCC label 50 mm x 16 mm
d
TW label 70 mm x 10 mm
e
Argentina label 68 mm x 6 mm
f
Indonesia label 26 mm x 10 mm
g
WL/BT label
Argentina 68 mm x 6 mm
Brazil 16.5 mm x 15 mm
US/CA/TW label
32 mm x 10 mm
Israel 32 mm x 10 mm
South Africa
20 mm x 10 mm
Belarus 40 mm x 8 mm
© Copyright Lenovo 2021 55
