Page #119 background image
Basic units in the power range 75 ... 90 kW
Mounting with fixing brackets and built-on mains filter (mounting variant 1)
5
Basic device installation
5.7
5.7.3
L
5.7-3
EDS82EV903-1.0-11/2002
5.7.3 Mounting with fixing brackets and built-on mains filter (mounting variant 1)
8200vec282
Fig. 5.7-3 Standard mounting with built-on mains filter 75 ... 90 kW (mounting variant 1)
 Loosebothscrewsinordertoremovethehousingcover.
 Mounting of the fixing brackets
 Dimensions
0
Mount the drive controllers side by side leaving a certain space for dismounting
the lifting-eye bolt.
Mains filter
Dimensions [mm]
8200 vector
M
a
n
s
f
t
e
r
type A or typ e B
a b c c1 c2 c3 d d1 e e1 f g k m
E82EV753K4B2x1 EZN3x0022H150
1
0
0
0
7
5
0
1
6
9
7
0
1
8
0
3
0
5
7
0
2
3
8
2
8
5
2
0
7
5
1
0
0
0
1
1
2
8
1
8
E82EV903K4B2x1 EZN3x0017H200
1000 750 16 970 180 30.5 702 38 285 207.5 1000 11 28 18
