Lenze E82EV752K4C User Manual

Behaviour in the event of mains switching, mains failure or controller inhibit
Start conditions/flying-restart circuit
10
Function library
10.5
10.5.1
L
10.5-1
EDS82EV903-1.0-11/2002
10.5 Behaviour in the event of mains switching, mains failure or
controller inhibit
10.5.1 Start conditions/flying-restart circuit
Determines the controller behaviour after a restart after controller inhibit, mains
switching or a mains failure.
With activated flying-restart circuit the controller automatically synchronises to a
coasting motor after mains disconnection or adds a setpoint signal.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0142
v
Start condition 1
0 Automatic restart after mains connection
inhibited
Flying restart not active
Start after HIGH-LOW-HIGH changes at
X3/28
^ 10.5-1
1 Automatic start, if X3/28 = HIGH
Flying restart circuit not active
2 Automatic restart after mains connection
inhibited
Flying-restart circuit active
Start after HIGH-LOW-HIGH changes at
X3/28
3 Automatic start, if X3/28 = HIGH
Flying restart circuit active
C0143* Selection of 0
0 Max. output fre quency (C0011) ... 0 Hz
Motor speed selected for the indicated ^ 10.5-1
v
flying-restart
1 Last output frequency ... 0 Hz
p
range
2 F requency setpoint addition (NSET1-NOUT)
The corresponding value is input after
3 Act. process controller value (C0412/5) a ddition
(PCTRL1-ACT)
p
g
p
controller enable.
Manual start (C0142 = 0):
After mains interruption the drive only restarts after a LOW/HIGH level change at
the ”Controller inhibit” terminal (X3/28).
Automatic start (C0142 = 1)
After mains interruption the drive only restarts if a HIGH level is applied to the
”controller inhibit”terminal (X3/28).
The controller sets all integrators to zero and releases them again.
Manual start with flying-restart circuit (C0142 = 2)
After mains interruption the drive only restarts after a LOW/HIGH level change at
the ”Controller inhibit” terminal (X3/28).
Automatic start with flying-restart circuit (C0142 = 3)
After mains interruption the drive only restarts if a HIGH level is applied to the
”controller inhibit”terminal (X3/28).
Description
Drive behaviour without
flying-restart circuit
Drive behaviour with
flying-restart circuit
