Preface and general information
About these Operating Instructions
1
53
EDBPM−H502 DE/EN/FR 5.1
1 Preface and general information
The operating unit enables you to access codes of Lenze controllers,
9300 Servo PLCs and Drive PLCs and to control them in a comfortable way.
Communication takes place via the system bus (CAN).
The Lenze »HMI Designer« software makes programming of the operating unit
easy.
1.1 About these Operating Instructions
ƒ These Operating Instructions serve to ensure safe and trouble−free
working on and with the operating unit.
ƒ All persons working on and with the operating unit must have these
Operating Instructions available and observe the information and notes
relevant for them.
ƒ These Operating Instructions must always be complete and perfectly
readable.
1.2 Terminology used
Term Used in this text for
Controller Lenze 8200 vector and 9300 vector frequency inverter, Lenze 9300
and 9400 servo inverter
HMI Human Machine Interface
1.3 Scope of supply
Scope of supply Important
l 1 EPM−H502 operating unit
l 1 Operating Instructions
l 4 mounting clamps
l 4 screws
l 1 seal
l 1 terminal block, 4−pin, for connection of DC
voltage supply
l 1 terminal block, 5−pin, for system bus (CAN)
connection
After receipt of the delivery, immediately check
whether the items delivered match the
accompanying papers. Lenze does not accept
any liability for deficiencies claimed
subsequently.
Claim
l visible transport damage immediately to the
forwarder.
l visible deficiencies/incompleteness
immediately to your Lenze representative.
