Technical data
Electrical data
2
57
EDBPM−H502 DE/EN/FR 5.1
2.2 Electrical data
Field Values
Display
Type
LCD 4 grey scale STN
Display format Graphical
Touchscreen Matrix 20 × 8 (12 × 16 pixels each)
Resolution 240 x 128 pixels
Visible size 94.5 × 54.5 mm
Lines × characters
Normal size
Double size
Quadruple size
16 × 40
8 × 20
4 × 10
Character size
Normal size
Double size
Quadruple size
2.3 × 5.2 mm, text: 6 × 8 pixels
4.6 × 5.8 mm, text: 12 × 16 pixels
9.1 × 11.7 mm, text: 24 × 32 pixels
Fonts Programmable
Contrast setting Software
Background illumination LED
Electrical
connection
DC voltage supply +24 VDC, (+18 ... 32 VDC)
Power consumption 10 W at 24 VDC
Fusing Miniature fuse Æ5 × 20 mm, 800 mA / F
Network:
System bus (CAN)
Protocol System bus (CAN)
Network topology Line (terminated at both ends with 120 W)
System bus node Master or slave
Max. number of nodes 63
Baud rate [kbps] 20 50 125 250 500 1000
Max. bus length [m] 2500 1000 500 250 80 25
Memory
User program 640 kB
Data memory (Flash
EPROM)
16 kB
Interfaces
Serial
ASP (8−pin Minidin socket) RS232
