Commissioning
Date/time and contrast setting
5

74
EDBPM−H502 DE/EN/FR 5.1
5.4 Date/time and contrast setting
You want to ... Touch the fields ... Example
A
set the date/time and contrast on the
display.
1. Briefly touch the display in one of the
corners , ,  or .
– Note: This corner must not contain
a selectable field.
2. Immediately touch the diagonally
opposite corner for a moment.
0
1
2
3
3. Select the menu for time/date and
contrast.
PROG
Port : NET
Driver : CAN Lenze M
Ver : X.XX
Addr : NO ADDRESS
Error : RESET
PROG
ESC
TRANS
PAGE
B
set date/time.
1. Touch the "SET CLOCK" field to select
the menu.
SET CONTRAST : 04
SET CLOCK:
Wed,13/09/00
12:50:10
ESC
2. Select the desired field.
or
ESC
12.50.10 13/09/00
3. Change the value.
or
4. If necessary, repeat steps 2. and 3. to
change additional values.
5. Confirm the input.
– The menu for time/date and
contrast is displayed.
C
set the contrast of the display.
1. Touch the "SET CONTRAST" field to
select the menu.
SET CONTRAST : 04
SET CLOCK:
Wed,13/09/00
12:50:10
ESC
2. Set the contrast.
CONTRAST : 04
ESC
More contrast
Less contrast
3. Confirm the input.
– The menu for time/date and
contrast is displayed.
D exit the date/time and contrast menu
and close the status display.
ESC
2x
