13.12 Frequency threshold for "Frequency threshold exceeded" trigger
As a funcon of the current output frequency, the adjustable frequency threshold serves to
trigger a certain funcon or set a digital output.
Parameter Name / value range / [default seng] Info
0x4005
(P412.00)
Frequency threshold
(Freq. threshold)
0.0 ... [0.0] ... 599.0 Hz
Threshold for the "Frequency threshold exceeded [70]" trigger.
•
The "Frequency threshold exceeded [70]" trigger is TRUE if the cur-
rent output frequency is higher than the set threshold.
•
The trigger can be assigned to a funcon or to a digital output.
Example for operang mode
In the following example, the digital output 1 is set to TRUE if the output frequency is higher
than 20 Hz.
•
The analog input 1 is set as standard setpoint source.
•
Switch S1 starts the motor in forward direcon of rotaon. Switch S1 in the inial posion
stops the motor again.
Connecon plan Funcon
GND AI1 AI2 AO1
10V 24V DI1 DI2 DI3 DI4 DI5 DO1
X3
S1
1k ...10k
0 ... 10 V
R1
Potenometer R1 Frequency setpoint selecon
Switch S1 Run
Parameter Name Seng for this example
0x2631:001 (P400.01) Enable inverter Constant TRUE [1]
0x2631:002 (P400.02) Run Digital input 1 [11]
0x2634:002 (P420.02) Digital outputs funcon: Digital output 1 Frequency threshold exceeded [70]
0x2824 (P200.00) Control selecon Flexible I/O conguraon [0]
0x2860:001 (P201.01) Frequency control: Default setpoint source Analog input 1 [2]
0x4005 (P412.00) Frequency threshold 20 Hz
t
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
-40 Hz
-60 Hz
-50 Hz
-30 Hz
-20 Hz
-10 Hz
t
t
t
t
t
t
0x2DDD
RunDigital input 1 [11]
Running [50]
Stop active [53]
Constant TRUE [1]
Frequency threshold exceeded [70]
Output signals
Status signals
Output frequency
Enable inverter
Input signals
Frequency setpoint selection
FunctionTrigger
The status signals can be assigned to digital outputs. 4Conguraon of digital outputs ^ 415
①
Frequency threshold 0x4005 (P412.00)
②
Frequency threshold exceeded: Via trigger "Frequency threshold exceeded [70]", the digital output 1 is set to TRUE.
Flexible I/O conguraon
Frequency threshold for "Frequency threshold exceeded" trigger
407
