Inial switch-on
Operang Instrucons i550-Cabinet
6 Inialswitch-on
DANGER
Electrical voltage
Incorrect wiring can cause unexpected states during the commissioning phase.
► Wiring must be complete and correct.
► Wiring must be free of short circuits and earth faults.
► The motor circuit conguraon (star/delta) must be adapted to the inverter.
► The motor must be connected in-phase (rotang direcon).
► The "emergency o" funcon of the overall system must operate correctly.
► Clear hazardous area.
► Observe safety instrucons and safety clearances.
Precondions
• The power connecons must be wired.
• The digital inputs X3/DI1 (start/stop), X3/DI3 (reversal) and X3/DI4 (frequency preset
20 Hz) must be wired.
• The analog input X3/AI1 must not be wired or connected to GND.
Switch on mains voltage
► Switch on mains voltage and check readiness for operaon.
Observe LED status displays “RDY” and “ERR” on the inverter front panel.
See „LED status“.
30
7 Commissioning
DANGER
Electrical voltage
Incorrect wiring can cause unexpected states during the commissioning phase.
► Wiring must be complete and correct.
► Wiring must be free of short circuits and earth faults.
► The motor circuit conguraon (star/delta) must be adapted to the inverter.
► The motor must be connected in-phase (rotang direcon).
► The "emergency o" funcon of the overall system must operate correctly.
► Clear hazardous area.
► Observe safety instrucons and safety clearances.
7.1 Keypad module
► Plug the keypad onto the inverter.
The keypad can also be connected and removed during operaon.

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
