8.4 LED status
LED“RDY”(blue) LED“ERR”(red) Status/meaning
o o No supply voltage.
Mains voltage is switched on, inverter is inialized.
ashes
o Inverter is disabled, ready for operaon.
ashes
Safe torque o (STO) acve, warning acve.
ashes
o Inverter inhibited.
ashes fast
Inverter disabled, warning acve.
Inverter disabled, error acve.
every 1.5 s on
Inverter disabled, no DC-bus voltage.
o Inverter enabled.
o The motor rotates according to the specied setpoint
or quick stop acve.
ashes fast
Inverter enabled, warning acve. The motor rotates
according to the specied setpoint or quick stop
acve.
ashes
Inverter enabled, quick stop as response to fault
acve.
9 Further documents
For certain tasks, informaon is available in further documents.
Document Contents/topics
Project Planning document Fundamental informaon on project planning and ordering the product
Commissioning document
Fundamental informaon for the installaon and commissioning of the product
Mounng instrucons Fundamental informaon on mounng the product
The documents can be found in the Lenze Doc Finder.
10 Disposal
If pollutants are disposed o improperly, they may cause a lasng damage to human health
and the environment. Thus, electrical and electronic equipment must be collected separately
from unsorted municipal waste so that it may be recycled or disposed of properly.
If available, put the components to the company internal disposal from where it is passed on
to specialized waste management companies.
It is also possible to return the components to the manufacturer. For this purpose, please
contact the customer service of the manufacturer.
More detailed informaon on disposal can be obtained from the corresponding specialist
rms and the competent authories.
The packaging of the component must be disposed of separately. Paper, cardboard and plas-
cs must be recycled.
11 Glossary
Abbreviaon Meaning
AIE Error acknowledgement (“Acknowledge In Error”)
OFF state Signal status of the safety sensor when it triggers or responds
QSP Quick stop

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
