Lenze i550 Series Instruction Manual

4
General informaon
Operang Instrucons i550-Cabinet
1 Generalinformaon
Please read this documentaon carefully before installing the inverter and observe the safety
instrucons!
This document only includes the most frequently asked quesons and presents them in a
simplied form for a beer overview. Detailed technical and funconal explanaons can be
found in the comprehensive product documentaon.
The complete documentaon, further informaon and tools regarding Lenze products can be
found on the Internet: hp://www.Lenze.com
1.1 Target group
Work on the product must only be carried out by qualied personnel. The personnel must
be qualied in accordance with the IEC 60364 or CENELEC HD 384. Qualied personnel are
persons who have the following knowledge and experience:
• They are familiar with the installaon, mounng, commissioning, and operaon of elect-
rical and electronic modules.
• They have the corresponding qualicaons for their work.
• They know and can apply all regulaons for the prevenon of accidents, direcves, and
laws applicable at the place of use.
1.2 Applicaonasdirected
The product is designed for the installaon into electrical systems or machinery.
The i500 product family is designed for the power range of 0.25 ... 132 kW. The inverter i550
is suitable for conveyor and travelling drives, pumps, fans, winders, liing systems and many
other machine tasks. The inverter is not to be used as a household appliance, but for com-
mercial or professional purposes only.
The inverter is not a machine in terms of the Machinery Direcve.
1.3 Device-specicstandardsanddirecves
• The product meets the protecon requirements of the Low-Voltage Direcve
2014/35/EU.
• The harmonized standard EN 61800-5-1 is used for the inverters.
1.4 Relevantstandardsanddirecvesfortheoperator
Applicaonasdirected
• If the product is used in accordance with the technical data, the drive systems comply
with the EN 61800-3 categories.
• The inverter may only be used commercially or professionally as dened by
EN 61000-3-2.
• The test voltage for insulaon resistance tests between a control potenal of 24 V and PE
must be measured in accordance with EN 61800-5-1.
• The cables must be installed in accordance with EN 60204-1 or US Naonal Electrical
Code NFPA 70 / Canadian Electrical Code C22.1.
Commissioning
• Commissioning or starng the operaon as directed of a machine with the product is pro-
hibited unl it has been ensured that the machine meets the regulaons of the Machine-
ry Direcve (2006/42/EC) and the standard EN 60204-1.
• Commissioning or starng the operaon as directed is only permissible if the EMC Direc-
ve 2014/30/EU is complied with.

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
