Lexicon MC-8 User Manual

Audio Controls Lexicon
4-4
AUDIO CONTROLS (continued)
TILT EQ –3.0dB to +3.0dB
Controls the amount of tilt equalization applied to the Main Zone
audio output connectors labeled Front L/R, Center and Subwoofer.
This parameter setting affects the entire frequency spectrum with a
hinge point at 1kHz. As the setting increases, frequencies higher
than 1kHz are boosted while frequencies lower than 1kHz are
simultaneously cut. As the setting decreases, frequencies higher
than 1kHz are cut while frequencies lower than 1kHz are
simultaneously boosted. The graph shown on the near right
indicates the frequency response of all TILT EQ parameter settings.
Note:
When the Zone 2 command bank is activated, pressing the remote control
Blue button sets the BASS, TREBLE and TILT EQ parameter to +0.0dB.
LOUDNESS ON, OFF
Controls the amount of low-frequency boost that is automatically
applied to the Main Zone audio output connectors labeled Front L/
R, Center and Subwoofer. When ON is selected, loudness
compensation is automatically applied, based on volume level. As
volume level increases, the amount of boost automatically
decreases. The loudness contour is optimized for input sources
calibrated to THX reference levels. When OFF is selected, no
loudness compensation is applied.
The graph shown on the far right indicates the frequency response
that is automatically applied when the LOUDNESS parameter is set
to ON and Main Zone volume level is adjusted.
AUDIO CONTROLS
BASS
TREBLE
TILT EQ
LOUDNESS
BALANCE
FADER
ZONE2 BALANCE
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
AUDIO CONTROLS
BASS
TREBLE
TILT EQ
LOUDNESS
BALANCE
FADER
ZONE2 BALANCE
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
ON
OFF
-3.0 to +3.0dB
AUDIO CONTROLS
TILT EQ
AUDIO CONTROLS
LOUDNESS
