Lexicon MC-8 User Manual

Setup Lexicon
3-26
SPEAKER SETUP PARAMETERS
The table below indicates the speaker setup parameters for config-
uring the Main Zone audio output connectors for the desired speaker
setup. These parameters are available on the CUSTOM SETUP and
THX SETUP menus.
Speaker setup parameters perform the same function regardless of
the selected speaker setup. When a parameter setting is adjusted on
one menu, the corresponding parameter setting is automatically
adjusted on the other menu. For example, when a THX speaker setup
is selected, the crossover settings on the CUSTOM SETUP menu are
set to THX 80Hz.
* These parameters cannot be adjusted on the THX SETUP menu.
† When the THX ULTRA2 SUB parameter is set to OFF, the BGC parameter is not available (N/A).
SPEAKERSSETUP SET CROSSOVERS CUSTOM SETUP
or
SPEAKERSSETUP
SET CROSSOVERS THX SETUP
Parameter
CUSTOM SETUP Menu THX SETUP Menu
Default Setting Possible Settings Default Setting Possible Settings
FRONT L/R* 40Hz FULL, FULL + SUB, 30 to 120Hz, THX 80Hz THX 80Hz THX 80Hz
CENTER* 60Hz FULL, FULL + SUB, 30 to 120Hz, THX 80Hz, NONE THX 80Hz THX 80Hz
SIDE L/R* 60Hz FULL, FULL + SUB, 30 to 120Hz, THX 80Hz, NONE THX 80Hz THX 80Hz
REAR L/R 60Hz FULL, FULL + SUB, 30 to 120Hz, THX 80Hz, NONE THX 80Hz THX 80Hz, NONE
SUBWOOFER* 40Hz FULL, 30 to 120Hz, THX 80Hz, NONE THX 80Hz THX 80Hz
THX ULTRA2 SUB OFF ON, OFF OFF ON, OFF
BGC N/A† ON, OFF N/A† ON, OFF
ASA APART APART, CLOSE, TOGETHER APART APART, CLOSE, TOGETHER
