Lexicon MC-8 User Manual

MC-8 Setup
3-59
REAR-PANEL CONFIGURATION
The REAR PANEL CONFIG option is used to configure the analog audio input connectors as eight (Left/Right) stereo connectors, five (Left/Right)
stereo connectors and one 5.1-channel configuration (Front L/R, Center, Subwoofer, Side L/R), or as two stereo connectors and two 5.1-channel
configurations.
8 STEREO INPUTS
Select the 8 STEREO INPUTS option to configure the analog audio
input connectors as eight stereo connectors.
When 8 STEREO INPUTS is selected:
• All analog audio input connectors are configured as stereo
connectors.
• The 5.1-channel connector is not available.
• Input sources that were assigned to the 5.1 ANLG (3-5) and 5.1
ANLG (6-8) are reassigned to the stereo connectors labeled 3
and 6, respectively.
REAR PANEL CONFIGSETUP
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
REAR PANEL CONFIG
8 STEREO INPUTS
OR
5 ST. & 5.1 ANLG
LIVE! CALIBRATION
OR
2 ST. & (2) 5.1 ANLG
REAR PANEL CONFIGSETUP 8 STEREO INPUTS
