ENGLISH_index
52
37. [White Balance Blue Offset] (Command: s z)
Adjusts the white balance blue offset value.
Transmission
(s)(z)( )(Set ID)( )(Data)(Cr)
Data 00~7F: Blue Offset 0 to 127
FF: Checks the blue offset value
Acknowledgement
(z)( )(Set ID)( )(OK/NG)(Data)(x)
38. [Backlight] (Command: m g)
Adjusts the backlight brightness.
Transmission
(m)(g)( )(Set ID)( )(Data)(Cr)
Data 00~64: Backlight 0 to 100
Acknowledgement
(g)()(set ID)()(OK/NG)(Data)(x)
39. [Screen Off] (Command: k d)
Turns the screen on or off.
Transmission
(k)(d)( )(Set ID)( )(Data)(Cr)
Data 00: Turns the screen on
01: Turns the screen off
Acknowledgement
(d)( )(Set ID)( )(OK/NG)(Data)(x)
* This may not be supported on some models.
* Dual-screen models must use the screen off commands in 88. Dual
Screen Off.
40. [Tile Mode] (Command: d d)
Sets the Tile Mode and sets values for the tile rows and columns.
Transmission
(d)(d)( )(Set ID)( )(Data)(Cr)
Data 00~FF: The first byte - Tile column
The second byte - Tile row
* 00, 01, 10, and 11 mean that the tile mode is off
* The maximum value may differ depending on the model.
Acknowledgement
(d)( )(Set ID)( )(OK/NG)(Data)(x)
* It may not be supported depending on the model.
41. [Check Tile Mode] (Command: d z)
Checks the tile mode.
Transmission
(d)(z)( )(Set ID)( )(Data)(Cr)
Data FF: Checks the tile mode
Acknowledgement
(z)( )(Set ID)( )(OK/NG)(Data1)(Data2)(Data3)(x)
Data1 00: Off (Tile mode off)
01: On (Tile mode on)
Data2 00~0F: Tile column
Data3 00~0F: Tile row
* It may not be supported depending on the model.
42. [Tile ID] (Command: d i)
Sets the tile ID value of the product.
Transmission
(d)(i)( )(Set ID)( )(Data)(Cr)
Data 01~E1: Tile ID 1 to 225**
FF: Checks the tile ID
* The data value cannot exceed the value of row x column.
Acknowledgement
(i)( )(Set ID)( )(OK/NG)(Data)(x)
* When a data value that exceeds the value of row x column is entered
(except 0xFF), ACK becomes NG.
* It may not be supported depending on the model.
