48. [Fail Over Input Select] (Command: m j)
Selects an input source for auto switch.
* This command is only available when the Fail Over (auto) mode is set
to Custom.
Transmission
(m)(j)( )(Set ID)( )(Data1)( )(Data2)( )(Data3)( )
(Data4)...( )(DataN)(Cr)
Data 1~N-1 (Input priority: 1~N-1)
40: COMPONENT
60: RGB
70: DVI-D
90: HDMI1
91: HDMI2/OPS
92: OPS/HDMI3/DVI-D
95: OPS/DVI-D
96: HDMI3/DVI-D
98: OPS
C0: DISPLAYPORT
Data N: E0: INTERNAL Memory
E1: USB
E2: SD CARD
Acknowledgement
(j)( )(SetID)( )(OK/NG)(Data1)(Data2)(Data3)(Data4)
...(DataN)(x)
* Some input signals may not be supported on some models.
* The data number (N) may vary depending on the model. (The data
number depends on the number of supported input signals.)
* Only values under Data N (e.g. E0, E1, E2) are allowed as the last data
value and may not be supported depending on the model.
* This feature operates as the last input and supports data in DTV format.
49. [IR Operation] (Command: t p)
Configures the IR operation settings of the product.
Transmission
(t)(p)( )(Set ID)( )(Data)(Cr)
Data 00: Locks off all of the keys
01: Locks on all of the keys except the Power key
02: Locks on all of the keys
Acknowledgement
(x)( )(Set ID)( )(OK/NG)(Data)(x)
* When the monitor is turned off, the power key works even in the locks
on all of the keys (02) mode.
50. [Local Key Operation] (Command: t o)
Configures the local key operation settings of the product.
Transmission
(t)(o)( )(Set ID)( )(Data)(Cr)
Data 00: Locks off all of the keys
01: Locks on all of the keys except the Power key
02: Locks on all of the keys
Acknowledgement
(o)( )(Set ID)( )(OK/NG)(Data)(x)
* When the monitor is turned off, the power key works even in the locks
on all of the keys (02) mode.
51. [Status] (Command: s v)
Checks the current signal status of the product.
Transmission
(s)(v)( )(Set ID)( )(Data)( )(FF)(Cr)
Data 02: Checks whether there is a signal or not
03: Check the PM mode.
07: Checks whether the Top, Bottom and Main
temperature sensors are functioning normally.
09: Fan Speed
10: RGB sensing OK/NG (Check Screen)
13: Door State
15: check the current electric current value
16: Humidity
17: Illuminance
18: Rotation(Gyro) State
Acknowledgement
(v)( )(Set ID)( )(OK/NG)(Data)(Data1)(x)
Data 02 (when a signal is found)
Data1 00: no signal
01: There is a signal
Data 03 (when checking the PM mode)
Data1 00: The PM mode is set to Screen On
01: The PM mode is set to Screen Off
02: The PM mode is set to Screen Off Always
03: In Sustain Aspect Ratio mode.
04: Screen Off & Backlight status (Outdoor mode)
Data 07 (In the case of checking whether the Top, Bottom and
Main temperature sensors are functioning normally)
Data1 00: All temperature sensors are faulty.
01: Top normal, Bottom faulty, Main faulty
02: Top faulty, Bottom normal, Main faulty
03: Top normal, Bottom normal, Main faulty
04: Top faulty, Bottom faulty, Main normal
05: Top normal, Bottom faulty, Main normal
06: Top faulty, Bottom normal, Main normal
07: All temperature sensors are normal
* The 4th temperature sensor determines whether a malfunction has
occurred or not, together with the Top.
