Lightware DA2DVI-DL - EDID Data Handling Commands

6. Programmer's Reference DA2DVI-DL – User's Manual 22
Delete EDID from Memory
Description: Clear EDID from memory location <loc>.
Explanation: All user EDIDs are cleared from memory.
Legend: Depending on <loc>, one EDID or all EDIDs in a block can be cleared.
Download EDID Content
Description: EDID hex bytes can be read directly. The router will issue the whole content of the EDID present

Legend
Explanation: Full EDID from memory location F1 is downloaded.
 Example
Command {DE<loc>}
→

Response (DE_OK)CrLf
(E_S_C)CrLf
←
←
(DE_OK)
(E_S_C)
<loc> Result
Fxx Not valid! Factory EDID cannot be deleted. No response.
Uxx 
Dxx 
Exx 
 Not valid! Factory EDID cannot be deleted. No response.
 All User EDIDs are deleted.
 All Dynamic EDIDs are deleted. They will be empty until a new monitor is connected.
 All Emulated EDIDs are cleared. By default F49 EDID is copied to them.
 Example
Command 
→
{wef1}
Response (EB#<loc>●<B1> ●<B2>●..●
CrLf
←
(EB#F1 00 FF FF FF FF FF FF 00 32 F2 00 00
00 .. .. .. 00 00)
Upload EDID Content to the Router
Description: EDID hex bytes can be written directly to the user programmable memory locations. The
sequence is the following:
Step 1. 
Step 2. Router responds that it is ready to accept EDID bytes with (E_L_S)CrLf
Step 3. Send 1 block of EDID (1 block consist of 8 bytes of hex data represented in ASCII format) with
●<B1>●<B2>●<B3>●<B4> ●●<B6>●<B7>●<B8>}
Step 4. The router acknowledges with response (EL#<num>)
Step 5. Repeat steps 3 and 4 to send the remaining 31 blocks of EDID (32 altogether)
Step 6. After the last acknowledge, the router indicates that the EDID status changed by sending (E_S_C)
CrLf
Legend: <num> represents the sequential number of every 8 byte part of EDID. <num> is between 1 and 32.

Explanation: Full EDID uploaded to memory location U3.
 Example
Command 
→
{wl#U3}
Response (E_L_S)CrLf
←
(E_L_S) CrLf
Command ●<B1>●<B2>●<B3>
●<B4>●●<B6>●<B7> ●<B8>}
→

Response (EL#<num>)CrLf
←
(EL#1) CrLf
Command ●<B9>●<B10>
●<B11>●<B12>●<B13>
●<B14>●●<B16>}
→

Response (EL#<num>) CrLf
←
(EL#2) CrLf
… …
Command ●<B249>●
●●●
●●●
→

Response (EL#<num>) CrLf
←
(EL#32) CrLf
Response (E_S_C) CrLf
←
(E_S_C) CrLf




