UMX-TPS-TX100 series – User's Manual 109
HDCP Setting (Input Port)
non-HDCP compliant display. See more information in the HDCP Management section.
#hdcp
ç in>.HdcpEnable=<logical_value>
æ in>.HdcpEnable=<logical_value>
Parameters
Parameter description Value Parameter value
<logical_value>
setting
true HDCP encryption is enabled.
false HDCP encryption is disabled.
Example
ç
æ
INFO: HDCP can be set for digital video inputs (I2, I3, I4) only. The function is unavailable on the analog
inputs (I1, I5).
Test Pattern Generator Mode
The output port can send a special image towards the sink device for testing purposes. The setting is
available on the input ports with the below-listed parameters.
Command and Response #testpattern #nosyncscreen
ç <in>.FreeRunMode=<mode>
æ <in>.FreeRunMode=<mode>
Parameters
Parameter description Value Parameter value
<mode>
Test pattern generator
mode
0
Always off: the test pattern is not displayed on
the output.
1
Always on: the test pattern is displayed on the
output.
2
Auto: the test pattern is displayed if there is no
signal on the input port.
Example
ç
æ
Test Pattern Color
Command and Response
ç <in>.FreeRunColor=<RGB_code>
æ <in>.FreeRunColor=<RGB_code>
Parameters
<RGB_code> RGB color in RR;GG;BB format (separated by semicolons).
Example
ç
æ
Test Pattern Resolution
Command and Response
ç <in>.FreeRunResolution=<resolution>
æ <in>.FreeRunResolution=<resolution>
Parameters
Parameter description Value Parameter value
<resolution>
Applied resolution of the
test pattern generator
0
1
2
3
4
5
6
7
8
9
10
11
Example
ç
æ
