4. Device Concept UMX-TPS-TX100 series – User's Manual 49
Consumer Electronics Control (CEC) Feature
DIFFERENCE:
UMX-TPS-TX140-Plus model is able to send and receive CEC commands, on HDMI IN (I2) port towards the
source, on HDMI OUT (O1) port towards the sink. For more information about sending CEC messages, see
section.
CEC Application Example
to wake up.
Create an event in the event manager:
▪ Set as a condition, that the signal is present on the output (O1),
▪ Set as an action then send a CEC command 'Image view on' O1 output port.
See the details about the Event Manager settings in the Event Manager section.
ATTENTION! The CEC command sending over TPS interface is working only with CEC-transparent
website.
Further Built-in Features
settings. If the devices are installed in the same type of system multiple times then it is enough to set up only
See more information about the settings in the section.
Restore section.
Software Control Modes
User has more possibilities to control the device besides the front panel buttons. The following list contains
the software control modes:
▪ Lightware Device Controller (LDC) - you can connect to the device via our control software using Ethernet
Software
chapter.
▪ LW2 protocol commands
protocol. For more details see the chapter.
▪ LW3 protocol commands
protocol. For more details see the chapter.
