 UMX-TPS-TX100 series – User's Manual 95

RS-232 Control Protocol Port Setting
The control protocol of local RS -232 port can be set as follows.
Command and Response #protocol
ȩ <protocol>}
Ȩ <protocol>
Parameters
Parameter Parameter description Value Parameter value
<protocol> RS-232 control protocol
LW2 
LW3 
Example
ȩ {rs232_local_prot=lw2}
Ȩ 
INFO: 
Serial Port Format Setting (Link port)
This command sets the format of the link RS-232 port (TPS port).
Command and Response
ȩ <baud_rate>;<data_bit>;<parity>;<stop_bit>}
Ȩ <baud_rate>;<data_bit>;<parity>;<stop_bit>
Parameters
See the previous section.
Example
ȩ 
Ȩ 
The databit and parity settings have not been changed.
Serial Port Protocol Setting (Link port)
This command sets the communication protocol of the link RS-232 port (TPS port).
Command and Response
ȩ <protocol>}
Ȩ <protocol>
Parameters
See the previous section.
Example
ȩ 
Ȩ 

DIFFERENCE: This section refers to the UMX-TPS-TX130, -TX140, TX140K and TX140-Plus models only.
Setting the Level and Direction for Each Pins
               GPIO - General
 section and about the interface in the GPIO Interface section.
Command and Response #gpio
ȩ {GPIO<pin_nr>=<dir>;<level>}
Ȩ (GPIO<pin_nr>=<dir>;<level>
Parameters
Parameter Parameter description  
<pin_nr> GPIO pin number
0-6
static
<dir> The direction of the communication
I
Input
O
Output
<level> The level of the pin
L

H
High
T
Toggle between low and high
Example
ȩ {gpio1=O;H}
Ȩ (GPIO1=O;H)
GPIO pin 1 is set to output with high level.
INFO: <pin_nr>
