UMX-TPS-TX100 series – User's Manual 112
Command and Response
ç
æ <out1_state>
the next 2-byte long HEX code showing the current state of the output port.
Example
ç
æ
Legend
See at previous section.
Example and Explanation
T 0 0 0 F
Unlocked,
Unmuted
0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1
Reserved Reserved Reserved Reserved Reserved Reserved
Signal
presents
Connected
Command and Response
ç
æ <in>
Example
ç
æ
I5 input port is connected to the output port.
Switching Audio Input
Command and Response #audio
ç <in>:<out>)
æ
Example
ç
æ
Command and Response
ç
æ <out_set>
The response shows the settings of each output one by one.
Parameters
Parameter description Value Parameter value
<out_set>
Two-letter code of the
Autoselect settings
1
st
letter
E Autoselect is enabled.
D Autoselect is disabled.
Two-letter code of the
Autoselect settings
2
nd
letter
F First detect
P
Priority detect: always the highest priority active
audio input will be selected.
L
Last detect: always the last attached input is
switched to the output automatically.
S
Static: the audio input follows the selected video
if the video signal contains embedded audio.
Example
ç
æ
Explanation
EL
INFO: For more information about the Autoselect feature see The Autoselect Feature section.
