3 -14
(10) Throttle pedal (Mechanical)
This pedal is used to control engine speed while
running on the road.
When using the throttle pedal, the throttle lever
must be placed on the low speed position.
Throttle pedal
▶ DO NOT ride your foot on the clutch pedal while driving.
▶ As a start safety switch is installed for the operator’s safety, depress the clutch
pedal fully for starting engine.
Caution
Clutch pedal
(11) Clutch pedal (Mechanical)
This is used to engage or disengage the main
transmission clutch for starting engine and
shifting transmission gear.
Depress the clutch pedal quickly and fully, and
release it slowly.
Even if depressing the clutch pedal, PTO shaft
can not be stopped. To stop the PTO shaft, turn
off the PTO switch.
Refer to the chapter 3-1-(7), “PTO switch” in this
manual.
