4 -29
(*) 1 : Front axle, 2 : Rear axle
Axle No.
(*)
Tires
Standard air
pressure (kg/cm2)
Load rating
per tire (kg)
Max. mass
per axle (kg)
Maximum
mass (kg)
1 7-16 4PR 76 A6 1.8 (180 KPa, 26 psi) 405 (893 lb) 810 (1786 lb)
2915
(6426 lb)
2
11.2-24 8PR 115
A6
2.4 (240 KPa, 35 psi) 1235 (2723 lb) 2105 (4641 lb)
1 8-16 4PR 82 A6 1.6 (160 KPa, 23 psi) 475 (1047 lb) 950 (2094 lb)
3008
(6631 lb)
2
12.4-24 8PR 120
A6
1.6 (160 KPa, 23 psi) 1445 (3186 lb) 2105 (4641 lb)
1 8-18 6PR 93 A6 1.6 (160 KPa, 23 psi) 660 (1455 lb) 1320 (2910 lb)
3008
(6631 lb)
2
13.6-24 8PR 124
A6
2.2 (220 KPa, 31 psi) 1615 (3560 lb) 2105 (4641 lb)
1 9.5-16 6PR 96 A6 2.2 (220 KPa, 31 psi) 725 (1598 lb) 1320 (2910 lb)
3008
(6631 lb)
2
13.6-24 8PR 124
A6
2.2 (220 KPa, 31 psi) 1615 (3560 lb) 2105 (4641 lb)
1
8.3-20 6PR 96 A6 2.4 (240 KPa, 35 psi)
710 (1565 lb) 1320 (2910 lb)
3008
(6631 lb)
2
12.4-28 6PR 116
A6
1.6 (160 KPa, 23 psi)
1275 (2811 lb) 2105 (4641 lb)
1 260/70R16 109 A8 2.4 (240 KPa, 34 psi)
1030 (2271 lb)
1320 (2910 lb)
3008
(6631 lb)
2 360/70R24 122 A8 1.9 (190 KPa, 27 psi)
1500 (3307 lb)
2105 (4641 lb)
1 250/75R16 120 G 4.5 (450 KPa, 64 psi)
1400 (3086 lb)
1320 (2910 lb)
3008
(6631 lb)
2 340/80R24 135 D 3.2 (320 KPa, 45 psi)
2180 (4806 lb)
2105 (4641 lb)
1 280/70R16 112 B 2.4 (240 KPa, 35 psi)
1200 (2646 lb)
1320 (2910 lb)
3008
(6631 lb)
2 360/70R24 122 B 1.6 (160 KPa, 23 psi)
1605 (3538 lb)
2105 (4641 lb)
1 250/80R16 113 A8 2.8 (280 KPa, 40 psi)
1290 (2844 lb)
1320 (2910 lb)
3008
(6631 lb)
2 360/70R24 122 B 1.6 (160 KPa, 23 psi)
1605 (3538 lb)
2105 (4641 lb)
1 280/70R16 112 B 2.4 (240 KPa, 35 psi)
1200 (2646 lb)
1320 (2910 lb)
3008
(6631 lb)
2 380/70R24 125 B 1.6 (160 KPa, 23 psi)
1770 (3902 lb)
2105 (4641 lb)
For safe operation and secure the reliability of the driveline, use only approved tire combination and
manage the specified tire air pressure regularly as below table. If using an unapproved tire
combination or unsuitable tire air pressure, it may cause failure of the front/rear axle and reduce the
reliability of the driveline.
(5) Tires and Load capacity
▶ Do not exceed the maximum permissible mass(Total/Front/Rear) declared by
manufacturer. Overloaded operation may invalidate the warranty. For further
information, refer to the chapter 4-5-(4) in this manual.
▶ If the front/rear tires have enough load capacity, the permissible mass on each
axle can be restricted by the maximum permissible mass of the front/rear axle.
Caution
To Next Page
