2 -3
▶ Operator’s condition : The persons such as patients, drunks, people on drugs,
etc. are never allowed to operate this tractor.
Only well educated operators can use the tractor after learning the usage of
controls for moving, stopping, turning and other operating.
▶ Do not grasp the gear levers when entering the cabin from the right-hand side.
2-1. Boarding and Exiting the tractor
Caution
② Cabin type
Whenever possible, use the left-hand side door
for entering.
To enter the cabin, release the locked cabin door
with the provided key and pull the cabin door grip.
When boarding the tractor, use the sub-step and
grab handles provided on the cabin frame and
door.
Do not jump up/down for your safety. Jumping
on/off the tractor could cause an injury. Always
face the tractor, use the handrails and steps, and
get on/off slowly. Maintain a three-point contact to
avoid falling: both hands on the handrails and one
foot on the step, or one hand on the handrail and
both feet on the steps.
Grab handle
Sub step
(1) Boarding the tractor
① Roll-Bar type
Whenever possible, use the left-hand side step
for entering.
When boarding the tractor, use the sub-step ,
steering wheel and grab handle on the left fender.
Do not jump up/down for your safety. Jumping
on/off the tractor could cause an injury. Always
face the tractor, use the handrails and steps, and
get on/off slowly. Maintain a three-point contact to
avoid falling: both hands on the handrails and one
foot on the step, or one hand on the handrail and
both feet on the steps.
Door grip
Sub step
Grab handle
To Next Page
