6. Air Conditioning System

6-1. The name of each part of cooling and heating system

Heater evaporator unit

Condenser

w/receiver drier

Cooler hose

Quick coupler

Compressor

Heater hose

▶ Maintenance of the air conditioning system and components (Compressor,

Receiver drier, Condenser, Heater evaporator unit and connection parts) must be

performed in a designated dealer. DO NOT disassemble the components arbitrary.

Caution
