M3 Mobile OX10 User Manual

Getting Started
11
Battery contact pin may bend or damaged not pull out properly.
Program error may be occurred when removing battery while any
program is running. Please make sure the running program is closed
before
The back-up battery would work when the battery has removed so the device goes
to sleep mode.
M3 ORANGE can be used for maximum 11 hours with fully charged
battery. It can be different depending on users’ working environment.
1.2.2 How to charge
If the exclamation mark shows up next to the battery icon, please charge the battery
otherwise the device will be turned off.
Charging the battery
 Plug in authentic AC adaptor plug to wall jack and DC jack to power
connector of cradle.
 Insert PDA to device slot to start charging the PDA. Make sure that the
device is connected to the cradle correctly.
AC adaptor is rated at 100~240V, 5A. Do not use the adapter outside the
rated voltage.
Please use authentic cradle that M3 Mobile provides only, there might be
a malfunction and/or failure of device.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
