M3 Mobile OX10 User Manual

Basic usage
24
2.5 Reset
2.5.1 Soft reset
When an unexpected error occurs while using the device, SOFT RESET allows your
device to restart, similar to rebooting a computer. It will adjust memory allocation -
all records and entries are retained after soft reset but unsaved data or files will be
lost.
 Press the RESET BUTTON briefly.
2.5.2 Clean boot
When an unexpected error cannot be solved with SOFT RESET, perform CLEAN
BOOT to restart the system. It will erase all data stored in the device except data
stored in Flash Disk and return to its default settings.
Follow below steps to CLEAN BOOT. ( or )
 Turn off the device by pressing the power button more than 10 seconds.
 Press and hold Right direction button then press the power button.
 ‘Clean Boot’ will be displayed on screen and press ‘3’ to precede clean boot.
 Device will be initialized after clean boot that is, clean boot deletes
everything except data stored in Flash Disk.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
