M3 Mobile OX10 User Manual

Getting Started
15
1.4 Memory card
1.4.1 Inserting memory card
M3 ORANGE uses MicroSD external memory card. The external memory slot is
located at the top side of the device as indicated in the following image:
To insert MicroSD, first open the top cover and slide in the external memory card in
the right direction until you feel a click.

M3 ORANGE with Windows Mobile 6.5 operating system supports up
to 32GB of external memory.
 Only use 2GB or less for OS update.
1.4.2 Data check
Stored data can be checked in StartFile ExplorerStorage Card.
For OS update using MicroSD, please refer to section 4.2.1 OS update via SD card.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
