M3 Mobile OX10 User Manual

Application usage
32
3.5 RFID
M3 ORANGE provides high (HF) or ultra high frequency (UHF) RFID reader as an
optional module. Please contact your local distributor for RFID options.
3.5.1 RFID basics
M3 Mobile provides two types of RFID program:
1. RfidEmul Keyboard wedge application which sends tag data.
2. RF_ID_Demo Used as RFID demonstration or quick tests.
When RfidEmul is running RFID icon ( ) will appear on task bar.
While RfidEmul is running, RF_ID_Demo cannot be used and vice versa.
<HF – 13.56MHz>
<Caen UHF – 868~956MHz>

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
