M3 Mobile OX10 User Manual

Getting Started
14
1.3 Power on & off
1.3.1 Power on
To turn on the device, attach fully charged main battery and press the power button
briefly.
Empty or low level of the back-up battery may cause starting problem. If
this happens press and hold the reset button for 5 seconds.
1.3.2 Power off
Press and hold the power button for more than 5 seconds to turn off the device.
1.3.3 Sleep mode
Device will automatically enter ‘Sleep mode’ to save battery if there is no constant
usage.
By default, backlight is turned off after 30 seconds of null state and will enter sleep
mode if the device is not used for 1 minute on battery power.
The time can be set from StartSettingsSystemBacklight for backlight off
time and StartSettingsPower for sleep mode.
In sleep mode, all modules except phone module are powered off which
causes Wi-Fi to disconnect from the current AP. However, on resume, Wi-
Fi is automatically re-connected to the AP normally within 10 seconds.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
