M3 Mobile OX10 User Manual

Application usage
30
3.3 GPS
M3 ORANGE provides Global Positioning System (GPS) and its test application.
3.3.1 GPS basics
The GPS application is located at \Flash Disk\GPS folder. The application provides
general positioning information, signal strength and satellite information as well as
the GPS start options.
Hot Start: Start mode of the GPS receiver when current position, clock offset,
approximate GPS time, and current ephemeris data are all available.
Warm Start: Start mode of the GPS receiver when current position, clock offset,
and approximate GPS time are input by the user. Ephemeris data is not available.
Cold Start: A condition in which the GPS receiver can arrive at a navigation solution
without initial position, time, and current Ephemeris.
1. GPS is an optional module.
2. Assisted GPS (AGPS) is only available with UBLOX GPS module.
Please click on version to check your GPS module.
For detailed description of GPS application, please refer to Application Manual.
Application Manual Download

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
