Basic usage
21
/ /
Volume status Indicates volume or vibration mode
/
Battery status Charging or left power amount
2.3.2 Today screen
There are program icons which can be added and/or deleted in home screen.
Icon
Name
Description
Date / Time Show the current date and time
Wireless
Information
Show the control panel for Bluetooth and phone
function.
Quick Guide
Show user manual that Microsoft supplies with
OS.
Owner information Show and set owner’s information.
Messaging
Show the text messages, e-mail through
outlook.
Task Information Show the tasks assigned.
Calendar Show Calendar
Live search Quick search bar
Lock Screen Lock screen.
2.3.3 Task bar
Task bar is controlled by third-party applications.
Icon
Name
Description
/
WLAN on / off Used to turn on / off WLAN

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
