M3 Mobile OX10 User Manual

Basic usage
25
2.6 Sync with PC
Sync is simplified form of Synchronization, which enables files transfer or back-up
data between PC and the device.
To synchronize the device with PC, one of the following sync programs must be
installed on the PC. Please download appropriate program depending on the
operating system of the PC
Sync program download
Windows Mobile Device Center (Windows Vista or later): Download
ActiveSync (Windows XP): Download
2.6.1 How to sync
To sync, please follow the steps described below.
1. Download and install WMDC (or ActiveSync) on PC.
2. Connect client port of the cradle and PC using supplied USB cable.
3. Supply AC power to the cradle.
4. Turn on the device and place it on the cradle.
After step 4, your PC will automatically detect M3 ORANGE and install Pocket_PC
driver. Once the driver installation is done successfully, you should be able to transfer
files or back up files on the device.
When you see a window similar to this, it
means your device is connected to the
PC correctly.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
