M3 Mobile OX10 User Manual

Application usage
29
3.2 Camera
3.2.1 Camera basics
M3 Mobile provides its own camera application for 3.0 MP AF camera with enhanced
features.
Camera is an optional module
How to launch
M3 camera application is located at \Flash Disk\Camera folder. To launch, click on
Camera.exe in the folder.
While the camera application is running, click on Capture button or press ‘C’ button
(right-up side key) to capture the image. You should be able to check the result
straight after the capture. Captured image is saved in the same folder (default path)
as the camera application.
For detailed description of camera application, please refer to Application Manual.
Application Manual Download
It may cause significant damage to your eyes if you directly look the
flash attached at camera module.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
